Megatron MT 3100 S2
The next generation: New Inline Homogenizing unit with EU-power cable, ready for App control (230 V)
When testing and optimizing formulas, high process safety is paramount. This system enables processing of complex material systems with absolutely minimal loss of mass and minimal energy. This miniature format production system delivers efficent, replicable results like those of our inline machines used in large volume production.
All prices are quoted on an EXW (Switzerland) basis and do not include packing, applicable taxes, or transport services.
* Items in stock, subject to prior sale. Order confirmation with definitive delivery date after receipt of order.
Description
When testing and optimizing formulas, high process safety is paramount. This system enables processing of complex material systems with absolutely minimal loss of mass and minimal energy. This miniature format production system delivers efficent, replicable results like those of our inline machines used in large volume production.
Benefits
The expert for your laboratory
This system was developed to help you realize your ideas under as realistic conditions as possible in small economic quantities. During subsequent scale-up, the results can be replicated with our large machines. Applications are mainly in recirculation mode.
Depending on the material’s system, the components bind into the finest emulsions or suspensions with droplet or particle sizes down to a few microns. These results are achieved by the machine’s high speed and the resulting peripheral tip speeds as well as precise rotor / stator geometry. Depending on the material’s system being process, the desired fineness is achieved after a certain period of recirculations and / or using other rotor / stator geometries.
Technical Information
| Power (W) | 1200 |
| Volume flow | up to approx. 11 l/min |
| Generators | Four different rotor/stator variants, single-stage |
| Product inlet | Single-phase (standard version) / Multi-phase (with optional injector) |
| Processing system | Inline product processing / Primarily used in recirculating operations |
| Working chamber | Horizontal, single-stage arrangement / Working pressure up to 6 bar / Working temperature up to 90 °C / Quick coupling for easy disassembly |
| Quick coupling for easy disassembly / Single-acting mechanical seal with pressureless quench system |
| Autoclavable working chambers are available / Viton, EPDM or Kalrez seals / Hose nipple connectors G1/8 “ or clamp connections |
| Accessories | Large selection of recirculation systems |
| Coupling / compatibility | Type F quick coupling for working chamber |
| Motor | 1200 W wear-free high-frequency AC motor / Gearless direct drive / Continuous speed control / Completely enclosed in stainless steel |
| Speed range | up to 30 000 rpm / autoclavable version up to 18 000 rpm |
| Sound level | < 62 dB(A) at 30 000 rpm (w/o load) |
| Supply voltage | 100 – 230 V ± 10 %, 50Hz / 60Hz |
| Relative humidity (max.) | 80 % in storage / 80 % during operation |
| Operating temperature | 0 – 40 °C |
| Protection class acc. to DIN | IP 20 |
| Dimensions (LxWxH) | 275 x 220 x 245 mm |
| Weight | 10 kg |
| EMC standards | IEC / EN 61000-6-2 / EN 61000-6-3 |
| Safety standard | IEC / EN 61010-2-51 |
Downloads
| Instruction Manual | English |  |
| Product brochure | English | |
| Bedienungsanleitung | German | |
| Produktbroschüre | German | |
| 产品手册 | Chinese | |
